• Visually striking, sculpted design in a low-resonance fibreglass enclosure
• Compact two-way reflex system
• High-performance coaxial driver with optimised neodymium motor design
• Controlled 80° x 80° dispersion for consistent coverage
• 400 W AES power handling
• Weather-resistant input glands with Phoenix connector and link-through functionality
• Weather protected with an IP-54 rating
• Hydrophobic membrane for enhanced ingress protection
• T80-style rear fixing points
• Supplied with a low-profile flush-mount bracket, positioning the Air 12 at a fixed 30° declining angle
• Optional tilt and swivel bracket

• Frequency response: 75 Hz - 20 kHz
• Efficiency¹: 98 dB 1W / 1M
• Nominal impedance: 8 Ω
• Power handling²: 400 W AES
• Maximum output³: 124 dB cont, 130 dB peak
• Driver configuration: 1 x 12”, 1 x 1” Coaxial
• Dispersion: 80° H x 80° V nominal coverage
• Connectors: 1 x Phoenix connector with link out
• Height: 424mm (17 inch)
• Width: 367mm (14 inch)
• Depth: 329mm (13 inch)
• Weight: 12.5 kg (27.6 lbs)
• Enclosure: Fibreglass composite
• Mounting: T80-style mounting, low profile flush-mount bracket included
• Grille: Perforated aluminium with foam filter and hydrophobic membrane
• Colour: Void Red, Black and White finishes, with RAL and Krome options upon request
• IP rating: IP-54
• Recommended Amplifier: Q1.5+ or higher

¹ Measured in half space ² AES2 - 1984 compliant ³ Calculated
